Front view
Click to zoom
Back view
Click to zoom
Close-up on sensor
Click to zoom
Install Futronic USB Fingerprint Scanner Device driver for Windows 10 x64, or download DriverPack Solution software for automatic driver installation and update. Buy Futronic provides drivers for automatic driver, USB 2. The scanner is able to adapt to fingerprint image quality wet, dry or blurred fingers by adjusting illumination intensity. The LFD feature is included in all Futronic s standard software. Logitech v-ual9. Futronic FS 88H USB Single Fingerprint Scanner. Device driver for Futronic FS 88H Single Fingerprint Scanner for non-Aadhaar enrollment and authentication. Futronic is FIPS201 / PIV Compliant View Details. FUTRONIC FINGERPRINT SCANNER 2.0 DRIVERS DOWNLOAD - The delivery fee will be displayed on the checkout page before your order is confirmed. Built-in live finger detection capability Free fingerprint capture software - Includes an application to capture and save a fingerprint image in bmp format Free API to capture fingerprint images Scratch resistant non-coated, hard. Instruction to download and install the driver for Futronic and Secugen fingerprint scanner1. Download the file3. Open the manual.
Futronic FS84 is an ethernet Fingerprint Authentication Module (eFAM) suitable for embedded, regular or remote applications. The module can be controlled via standard Ethernet interface by any host system or via serial interface.
1 output channel (for external relay control) and 2 input channels (for door sensor and switch) are available for external device control. Electric lock or other electric device can be activated by eFAM using these output control signals.
Support modules for this device are included in MegaMatcher 12.1 SDK, MegaMatcher On Card 11.2 SDK, VeriFinger 12.1 SDK and Free Fingerprint Verification SDK.
Specifications
| Scanner Name | Futronic FS84 ethernet Fingerprint Authentication Module (eFAM) |
| Manufacturer | Futronic Technology Co. Ltd. |
| Connection | Ethernet or Serial |
| Supported OS (*) | Microsoft Windows (32-bit and 64-bit), Android, Linux x86 (32-bit and 64-bit), ARM Linux (32-bit and 64-bit) |
| Resolution | 500 ppi |
| Image capture area (Platen size) | 16 x 24 mm (0.6' x 0.9') |
| Fingerprint image size | 320 x 480 pixels |
| Sensor type | Optical, CMOS |
| Illumination | Infrared LEDs |
| Device size | 106 x 76 x 41 mm (4.2' x 3.0' x 1.6') |
| Device weight | 200 grams (0.4 lbs.) |
| Operating temperature | -10°C ~ +55°C |
| Operating humidity | Scanning window is waterproof |
* These operating systems are supported by Neurotechnology SDKs. Device manufacturers may have different lists of supported operating systems.
Where to order this device?
Buy eFAM at Biometric Supply – a subsidiary of Neurotechnology.
Other Futronic scanners
Neurotechnology SDKs also include support modules for these Futronic scanners:
- FS10 – a single finger scanner with 1' x 1' platen and PIV / FIPS 201 certification
- FS26 – a single finger scanner with MIFARE card reader/writer
- FS26EU – a single finger scanner with PIV / FIPS 201 certification and embedded smart card reader (ISO7816 contact and MIFARE cards supported)
- FS28 – a single finger scanner with bluetooth connection
- FS50 – a two finger scanner with PIV / FIPS 201 certification
- FS60 – a four finger scanner with FBI Appendix F certification
- FS64 – a four finger / rolled fingerprint scanner with FBI Appendix F certification
- FS80 – basic Futronic FS80-series scanner
- FS82 – a version of FS80 with embedded smart card reader
- FS88 – an enhanced version of FS80 with PIV / FIPS 201 certification
- FS90 – a compact scanner most suitable for using with notebook PCs, handheld devices and mobile phones
at Biometric Supply,
a subsidiary of Neurotechnology.
General view
Click to zoom
FS64 from Futronic is an optical ten-finger reader which is certified by the FBI as compliant with IQS IAFIS Appendix F. The reader is able to scan four-finger slaps, dual thumbs, as well as single rolled and flat fingerprints.
The manufacturer specifies that FS64 features IP54-rated sealed casing. The device is USB-powered and does not require dedicated power supply.
Support modules for this scanner are included in MegaMatcher 12.1 SDK, MegaMatcher On Card 11.2 SDK and VeriFinger 12.1 SDK.
Specifications
| Scanner Name | FS64 ID Flat Fingerprint Scanner |
| Manufacturer | Futronic Technology Co. Ltd. |
| Connection | USB 2.0 |
| Supported OS (*) | Microsoft Windows (32-bit and 64-bit), Linux, Android |
| Resolution | 500 ppi |
| Image capture area (Platen size) | 81 x 76 mm (3.2' x 3.0') |
| Fingerprint image size | 1600 x 1500 pixels (slaps and flats) 800 x 750 (rolled) |
| Sensor type | Optical, CMOS |
| Illumination | Infrared LEDs |
| Device size | 152 x 149 x 155 mm (6.0' x 5.9' x 6.1') |
| Device weight | 2.1 kg (4.6 lbs) |
| Operating temperature | 0°C ~ +50°C |
| Operating humidity | 0-90 % (non-condensing) |
* These operating systems are supported by Neurotechnology SDKs. Device manufacturers may have different lists of supported operating systems.
Neurotechnology Solution Partners use this scanner in
Futronic FS64 scanners are used in the Online Beneficiary Claims System – an identity verification system created by MWETANA Consulting and Technology Group, a Neurotechnology Solution Partner.
Where to order this device?
Futronic Scanner Driver
Buy FS64 at Biometric Supply – a subsidiary of Neurotechnology.
Driver Futronic Fingerprint Scanner Fs80h
Other Futronic scanners
Futronic Fs82 Driver Download
Neurotechnology SDKs also include support modules for these Futronic scanners:
Futronic Fingerprint Scanner 2.0 Driver
- eFAM (FS84) – an embedded fingerprint scanner solution
- FS10 – a single finger scanner with 1' x 1' platen and PIV / FIPS 201 certification
- FS26 – a single finger scanner with MIFARE card reader/writer
- FS26EU – a single finger scanner with PIV / FIPS 201 certification and embedded smart card reader (ISO7816 contact and MIFARE cards supported)
- FS28 – a single finger scanner with bluetooth connection
- FS50 – a two finger scanner with PIV / FIPS 201 certification
- FS60 – a four finger scanner with FBI Appendix F certification
- FS80 – basic Futronic FS80-series scanner
- FS82 – a version of FS80 with embedded smart card reader
- FS88 – an enhanced version of FS80 with PIV / FIPS 201 certification
- FS90 – a compact scanner most suitable for using with notebook PCs, handheld devices and mobile phones
